機器型號 Model | 1200mm PTFE推擠機 1200mm PTFE Cold Extrusion Line | 2700mm PTFE推擠機 2700mm PTFE Cold Extrusion Line |
| 結構型式Structure type | 立式結構 Vertical | 臥式結構 Horizontal |
| 推擠電機Cold-extruded motor | 4.5KW Servo+5KW AC | 50T雙油壓缸推動Double hydraulic cylinder |
| 最大推力Cold-extruded force (Max): | 35T | 100T |
| 牽引電機Capstan power | 400W | 2000W |
| 放線電機Pay-off power | 750W | 5500W |
| 收線電機Take-up power | 750W | 2200W |
| 揮發箱功率Volatile-tank power | 8KW | 15KW |
| 燒結爐功率Sintering furnace power | 45KW | 45KW |
| 溫度范圍Temperature range | 0~500℃ ±1℃ | 0~500℃ ±1℃ |
| 設計線速Design line speed | 0~50(40)m/min | 0~80(40)m/min |
| 機組平面尺寸Plane size of machines | 9280mm*2500mm | 19000mm*2500mm |
| 機器高度Machines height | 13500mm | 13500mm |
